Assurance
Quality Inspection List
2017 Gauge Instrument list and calibration plan list | ||||||||||
Serial number | Instrument name | Instrument number | manufacturer | Calibration period | Calibration date | specification |
Calibration mode |
User department | Description of action | |
External calibration | Internal calibration | |||||||||
1 |
Electronic digital display micrometer |
APL-A-09 |
AIGU |
A year |
On or before August 10 of each year |
0-25mm |
√ |
|
IQC |
Substrate thickness detection |
2 |
Electronic digital display micrometer |
APL-A-10 |
Special code |
A year |
0-25mm |
√ |
|
Drilling/opening |
Drill diameter detection |
|
3 |
Electronic digital display micrometer |
APL-A-11 |
Guanglu |
A year |
0-25mm |
√ |
|
Board warehouse |
Substrate thickness detection |
|
4 |
Copper foil grading thickness gauge |
APL-A-13 |
Three times |
A year |
9-105um |
√ |
|
IQC |
Substrate copper foil thickness detection |
|
5 |
Copper foil grading thickness gauge |
APL-A-14 |
Three times |
A year |
9-105um |
√ |
|
Drilling/opening |
Substrate copper foil thickness detection |
|
6 |
Hundredfold mirror |
APL-A-16 |
Regular occupation |
A year |
0-1.2mm |
√ |
|
Circuit house |
Wire width measurement |
|
7 |
Hundredfold mirror |
APL-A-17 |
Regular occupation |
A year |
0-1.2mm |
√ |
|
Line QA |
Wire width measurement |
|
8 |
Hundredfold mirror |
APL-A-19 |
Regular occupation |
A year |
0-1.2mm |
√ |
|
Electroplating QA |
Wire width measurement |
|
9 |
Digital display calipers |
APL-A-02 |
GUOGEN |
A year |
0-250mm |
√ |
|
IQC |
Contour measurement |
|
10 |
Vernier calipers |
APL-A-03 |
深圳精量 |
A year |
0-250mm |
√ |
|
Molding/gong room |
Contour measurement |
|
11 |
V-CUT residual thickness tester |
APL-A-15 |
深圳精量 |
A year |
0-25mm |
√ |
|
Molding /V-CUT |
V cut residual thickness measurement |
|
12 |
Digital display calipers |
APL-A-04 |
GUOGEN |
A year |
0-250mm |
√ |
|
Molding/punching press |
Contour measurement |
|
13 |
Needle gauge |
APL-B-07 |
Regular occupation |
A year |
0.25-6.25 |
√ |
|
FQA |
Finished aperture measurement |
|
14 |
Needle gauge |
APL-B-08 |
Regular occupation |
A year |
0.25-6.25 |
√ |
|
borehole |
borehole Measurement of the borehole |
|
15 |
CMI700 hole copper measuring instrument |
APL-A-20 |
Oxford |
A year |
2.032-101.6um |
|
√ |
electroplating |
Copper plating thickness measurement |
|
|
CMI700 hole copper measuring instrument |
APL-A-05 |
Oxford |
A year |
2.032-101.6um |
|
√ |
QA |
Copper plating thickness measurement |
|
16 |
Second element (image measuring instrument) |
APL-A-31 |
Tako |
A year |
0-600mm |
√ |
|
QA |
Contour measurement |
|
17 |
Metallographic microscope |
APL-A-18 |
Regular occupation |
A year |
0-10mm |
√ |
|
Physics laboratory |
Microslice measurement |
|
18 |
Metallographic microscope |
APL-A-30 |
Regular occupation |
A year |
0-10mm |
√ |
|
electroplating |
Microslice measurement |
|
19 |
Vernier calipers |
APL-A-01 |
Dayang |
A year |
0-300mm |
√ |
|
FQA |
Contour measurement |
|
20 |
Electronic scale |
APL-A-06/12 |
Pengcheng |
A year |
1-2000g |
√ |
|
Printing and packaging |
Package quantity check |
|
21 |
Marble platform |
APL-A-21 |
Dongguan Jinheng |
A year |
/ |
|
√ |
FQC |
Detection of warping degree of finished product |
|
22 |
Digital display thermometer |
APL-E-22/23 |
TES |
A year |
1-300° |
√ |
|
electroplating, printing |
Potion, oven temperature detection |
|
23 |
Impedance tester |
APL-A-24 |
pilot |
A year |
/ |
√ |
|
laboratory |
Impedance measurement |
|
24 |
ROHS tester |
APL-A-25 |
Zhipu element |
A year |
/ |
√ |
|
laboratory |
Lead-free environmental testing |
|
25 |
Voltage tester |
APL-A-26 |
Tonghui electronics |
A year |
/ |
√ |
|
laboratory |
Insulation resistance to high pressure test |
Quality assurance testing equipment
![]() |
![]() |
![]() |
electroplating chemistry laboratory |
Hole copper measuring instrument | Turn on the short-circuit flying needle tester |
![]() |
![]() |
![]() |
Open road high pressure tester | Quadratic element | AOI scanner |
![]() |
![]() |
![]() |
Warpage test table |
ROHS tester |
Voltage tester |
![]() |
![]() |
![]() |
Impedance tester |
Tin test furnace | Slice polishing machine |
![]() |
![]() |
![]() |
Mail label calipers |
Needle gauge |
Ten-fold mirror |
![]() |
![]() |
![]() |
microscope | Automatic testing machine | X-RAY screening machine |
